MG0832 Series mobile IoT uses 7.9 inch high-brightness display, with toughened touch panel,which enhances with UHF RFID , fingerprint, barcode, high-precision GNSS, and various sensors as the date collecting ways. With Titanium alloy frame, cases made by bicolor mold, it is backed by MIL-STD-810G/Method516.6/Procedure IV for durability and protection against dirt, dust, water and motion. Also it goes with a long-life 10000mAh battery, sunlight-readable, and operating under extreme low temperature.It can fully realize control of the community, GIS surveying, Inventory, goods traceability, drug safety supervision and management of industrial processes, etc.
*If you require SDK-s for advanced integration, please contact our tech department [email protected]
CPU | 2.5G Hz x10 Cortex A72 Deca-Core 64bit |
---|---|
RAM/ROM | 3G+32G EMCP |
Display | 7.9 inch IPS/AFFS 768*1024 industrial 420CD/M2 Sunlight -Readable |
Touch Panel | Capacitive / toughened glass TP 9H support glove touch/spray/Active capacitance pen |
Basic Function | 2G/3G/4G/BT/GPS/WIFI/FM/Gyro-Sensor/MSensor/G-Sensor/Motion-sensor/ |
Extensible Function | LF/UHF RFID/ NFC/GNSS/RTD/RTK/38K/Zigbee |
Camera | 13.0MP(AF)with flash led/5.0MPsub Camera |
Network | 2G/3G/4G Band, GSM, B2/3/5/8, WCDMA, B1/2/5/8, TDSCDMA, B34/39, TD-LTE, B38/39/40/41, FDD LTE, B1/2/3/4/5/7/20, EVDO,CDMA 1X |
WiFi | Dual-band (2.4GHz/5Ghz) 802.11a/b/g/n MAC/BB/RF, BT v2.1+EDR/BT 3.0+HS / BlT v4.0 (LE) |
Conformity | CE RoHS |
